ROTOR DISC » RN1887V

Specification

Type
Vented
Outter Ø
260
Num. of holes
4
Disc Thickness (Max)
22
Height
44
Centering Diameter
61
Pitch Circle Ø
100
Front/Rear
Front
Disc Thickness (Min)
20
Drum Ø:
129
Structure Material
G3000

Cross Reference

NISSAN
40206-1HA0A
NISSAN
40206-1HA0B
NISSAN
40206-1HD0A
NISSAN
40206-1HJ0A
NISSAN
D0206-1HA0A-VA
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.15~09.21 1200 HR12DE AD0KK RN1887V PN6427
01.18~02.20 1200 HR12DE UAD0N RN1887V PN9805 FN0619
01.77~10.80 2000 L20 C230 RN2194VRN1887V PN3469PN2180 FN1167PN2466
02.10~ 1200 HR12DE BUK13 RHD RN22003VRN1887V PN0397 DN1305DN1328 FN1264FN1280FN1289
07.10~06.20 1200 HR12DE K13 JPN RN1887V PN0397 DN1328 FN1280
07.10~06.20 1200 HR12DE NK13 JPN RN1887V PN0397 FN1264
07.10~10.15 1200 HR12DE K13K RN22003VRN1887V PN9805PN0397 DN1288DN1305 FN1289FN0619
03.11~ 1200 HR12DR K13K RN1887V PN9805PN0397 DN1288 FN1280FN1264FN0619
05.11~10.15 1500 HR15DE K13K RN1887V PN9805 DN1288 FN0619
09.12~11.16 1200 HR12DE E12Z097 RN1887V PN9805 FN1289
08.13~11.16 1500 K9K E12E RN1887V PN9805 FN0619
12.11~06.15 1500 HR15DE N17K RN1887V PN9805 DN1288 FN0619
06.15~ 1500 HR15DE N17KK GL RN1887V PN9805 DN1288 FN0619
09.11~06.15 1500 HR15DE N17K RN1887V PN9805 DN1288 FN0619

Exemption from liability: the catalog data is advisory and can be used for reference only
