ROTOR DISC » RN1916V

Specification

Type
Vented
Outter Ø
326
Num. of holes
5
Disc Thickness (Max)
30
Height
46
Centering Diameter
71
Pitch Circle Ø
108
Drum Ø:
161
Front/Rear
Front
Structure Material
G3000
Disc Thickness (Min)
28

Cross Reference

JAGUAR
C2C 25336
JAGUAR
C2P 26267
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.11~05.15 2000 204PT X250 RN1918VRN1916V PN0462WPN0683W RN1917V PN2702
01.08~05.11 2200 224DT X250 RN1916V PN0462W RN1917V PN2702
04.11~04.15 2200 224DT X250 RN1916V PN0462W RN1917V PN2702
03.08~04.15 3000 AJ30 C05D RN1916V PN0462W RN1917V PN2702
03.08~04.11 3000 AJ30 C06D RN1916V PN0462W RN1917V PN2702
01.08~04.11 3000 AJ30 X250 RN1916V PN0462W RN1917V PN2702
01.03~12.10 3000 AJV6 X350 RN1916V PN0462W RN1917V PN2702
05.04~05.09 3000 AJ30 X350 RN1916V PN0683W RN1917V PN2702
04.03~12.10 3500 AJ-V8 X350 RN1916V PN0462W PN0146
04.03~02.07 4200 AJ33 X350 RN1916V PN0462WPN0142 RN1917V PN0146PN2702
03.07~03.09 4200 AJ8F X358 RN1916V PN0462W RN1917V PN2702
03.12~ 3000 AJ126 X351 RN1916V PN0462W RN1917V PN2702
01.06~01.09 4200 AJ40 C44P RN1916V PN0462W RN1917V PN2702
01.06~01.15 4200 AJ40 XK RN1916V PN0462WPN0683W RN1917V PN2702
03.06~07.14 4200 AJ8FT X150 RN1916V PN0462W RN1917V PN2702

Exemption from liability: the catalog data is advisory and can be used for reference only
