ROTOR DISC » RN1947

Specification

Type
Solid
Outter Ø
284
Num. of holes
5
Disc Thickness (Max)
10
Height
45
Centering Diameter
76
Pitch Circle Ø
114.3
Drum Ø:
184.2
Front/Rear
Rear
Disc Thickness (Min)
8.4
Structure Material
G3000

Cross Reference

HYUNDAI / KIA
58411-B2500
KIA
58411-A4000
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
06.17~ 1600 D4FB PJ918 LHD RN1548V PN0373 RN1947 PN0436
07.17~09.20 1600 G4FJ PJ918 RN1653V PN0578 RN1947 PN0436
01.13~09.16 1600 G4FD HU81 RHD RN1348V PN0799 RN1947 PN0538
12.12~08.16 1700 D4FD WAGON - 5DR 7P RN1348V PN0799 RN1947 PN0538
01.13~ 2000 G4NA MPV LHD RN1348V PN0799PN0537 RN1947 PN0538
01.13~09.16 2000 G4NC HU RN1348V PN0799 RN1947 PN0538
01.13~09.16 2000 G4ND RPA412 RN1348V PN0799 RN1947 PN0538
01.13~09.16 2000 L4NA DOMPA412 RN1348V PN0799 RN1947 PN0538
08.16~07.18 1700 D4FD WAGON - 5DR 7P RN1348V PN0537 RN1947 PN0538
01.13~12.17 1700 D4FD HU81 RN1348V PN0799 RN1947 PN0538
06.19~ 1600 G4FJ PTH19 RN1653V PN0578 RN1947 PN6136

Exemption from liability: the catalog data is advisory and can be used for reference only
