ROTOR DISC » RN2518V

Specification

Type
Vented
Outter Ø
298
Num. of holes
5
Hole Ø:
15.6
Disc Thickness (Max)
28
Disc Thickness (Min)
26
Height
64.7
Centering Diameter
71.8
Pitch Circle Ø
114.3
Drum Ø:
161
Front/Rear
Front
Structure Material
G3000

Cross Reference

BENDIX AUS
BR504
FORD
AY1125A
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.02~09.05 4000 BARRA 182 BA RN2518V PN0826 RN2425 PN0420
02.08~12.14 4000 BARRA 195 FG RN2518V PN0826PN0339 RN2425 PN60001PN0202WPN0420 FN0696

Exemption from liability: the catalog data is advisory and can be used for reference only
