ROTOR DISC » RN2522V

Specification

Type

Vented

Outter Ø

257

Num. of holes

4

Hole Ø:

14.5

Disc Thickness (Max)

22

Disc Thickness (Min)

19

Height

45.2

Centering Diameter

55

Pitch Circle Ø

100

Drum Ø:

130.5

Front/Rear

Front

Structure Material

G3000

Cross Reference

TOYOTA

43512-0D160

TOYOTA

43512-0D170

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Etios

09.12~	1300	1NR-FBE	NGK11	RN2522V	PN1853	DN1241	FN2386
04.16~	1500	2NR-FE	NGK15L	RN2522V	PN1853	DN1241	FN2386

TOYOTA » Etios Liva

04.16~

1500

2NR-FE

NGK15L

RN2522V

PN1853

DN1241

FN2386
