ROTOR DISC » RN2072V

Specification

Type
Vented
Outter Ø
280
Num. of holes
4
Disc Thickness (Max)
22
Disc Thickness (Min)
19.4
Height
43.8
Centering Diameter
62.2
Pitch Circle Ø
100
Drum Ø:
143.5
Front/Rear
Front
Structure Material
G3000

Cross Reference

HYUNDAI
51712-1W050
HYUNDAI
51712-C8500
HYUNDAI / KIA
51712-C8600
HYUNDAI / KIA
51712-H8500
HYUNDAI / KIA
51712-H8580
KIA
51712-1W000
KIA
51712-1W050
KIA
51712-H8530
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.18~ 1600 G4FD PJ018 RN2072V PN0603 DN1509 FN0609
03.21~ 1000 G3LF PSW21 RN2072V PN0603 RN11003 PN0538
03.21~ 1200 G4LF PSW21 RN2072V PN0603 RN11003 PN0538
03.21~ 1400 G4LC PSW21 RN2072V PN0603 RN11003 PN0538
01.16~06.18 1000 G3LC HB EU RN1956VRN2072V PN0537 DN1456RN11003 FN0609PN0538
06.18~03.20 1000 G3LC PC818 5DR HB EL RN2072VRN1956V PN0537 DN1456RN11003 PN0538FN0609
11.14~06.18 1100 D3FA HB EU RN2072VRN1956V PN0537 DN1456RN11003 PN0538FN0609
11.14~06.18 1200 G4LA HB EU RN1956VRN2072V PN0537 RN11003DN1456 PN0538FN0609
11.14~09.17 1200 G4LA PC715 RHD RN11002VRN2072V PN0537 RN11003DN1456 FN0609PN0538
11.14~06.18 1400 D4FC HB EU RN2072VRN1956V PN0537 DN1456RN11003 FN0609PN0538
06.18~03.20 1400 G4LC GB RN2072VRN1956V PN0537 DN1456RN11003 FN0609PN0538
11.14~06.18 1400 G4LC HB EU RN2072VRN1956V PN0537 DN1456RN11003 PN0538FN0609
09.14~ 1400 D4FC DN51 RN2072V PN0537 RN11003 PN0538
01.17~09.20 1000 G3LC AD68 RN2072V PN0603 RN11003 PN0538
09.20~ 1000 G3LC AD68 RN2072V PN0603 RN11003 PN0538
05.19~ 1000 G3LE H820 RN2072V PN0603 RN11003 PN0538
10.20~ 1400 G4LC H820 RN2072V PN0603 RN11003 PN0538

Exemption from liability: the catalog data is advisory and can be used for reference only
