BRAKE SHOE » FN0726

Specification

Radius
90
Width
26.5
Thickness
6.6
Pcs In Set
4

Cross Reference

HONDA
43153-TG1-T01
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
12.15~02.18 1200 L12B3 DF1 LHD PN8824 DN1382 FN0726
04.13~02.18 1200 L12B3 DF1 RHD PN8824 DN1382 FN0726
12.15~02.18 1300 L13Z1 DF1 GL PN8824 DN1382 FN0726
01.11~05.18 1200 L12B DD1 PN8824 DN1382 FN0726
01.11~05.18 1200 L12B DD1LHD PN8824 DN1382 FN0726
01.11~05.18 1300 L13# DD2 FN0726

Exemption from liability: the catalog data is advisory and can be used for reference only
