ROTOR DISC » RN3002V

Specification

Type
Vented
Outter Ø
315
Num. of holes
6
Hole Ø:
12.6
Disc Thickness (Max)
18
Disc Thickness (Min)
16.4
Height
84.4
Centering Diameter
94
Pitch Circle Ø
139.7
Front/Rear
Rear
Drum Ø:
188
Structure Material
G3000

Cross Reference

MITSUBISHI
4615A224
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
04.14~ 2400 4N15 KR1W RN3001V PN3813 RN3002V PN3391 FN0567
10.15~ 2400 4N15 KS1W RN3001V PN3813 RN3002V PN3391 FN0567
10.15~ 2500 4D56 KR3W RN1247V PN3809 DN1104RN3002V PN3391FN6741 FN0567
10.15~ 3000 6B31 KR5W RN3001V PN3813 RN3002V PN3391 FN0567
10.15~03.21 3000 6B31 KS5W RN3001V PN3813 RN3002V PN3391 FN0567
03.17~ 2400 4N15 KR1W RN3001V PN3813 RN3002V PN3391 FN0567
10.15~ 2400 4N15 KS1W RN3001V PN3809PN3813 RN3002V FN0567
10.15~ 2500 4D56 KS3W RN1247V PN3809 DN1104RN3002V FN6741PN3391 FN0567
08.19~ 3000 6B31 KS5W RN3001V PN3813 RN3002V PN3391 FN0567

Exemption from liability: the catalog data is advisory and can be used for reference only
