NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2786V

Product
Application

ROTOR DISC » RN2786V

Specification

Type

Vented

Outter Ø

354

Num. of holes

5

Hole Ø:

17

Disc Thickness (Max)

28

Disc Thickness (Min)

26

Height

52

Centering Diameter

72

Pitch Circle Ø

127

Drum Ø:

174

Front/Rear

Front

Structure Material

G3000

Cross Reference

CHRYSLER

68340 474AA

CHRYSLER

68340 474AB

CHRYSLER

68463 427AA

CHRYSLER

68463 427AB

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

JEEP » Grand Cherokee

05.21~	2000	EC1	WL	RN2788V RN2786V	PN53018 PN53013	RN2787V RN2789	PN53020 PN53017
05.21~	2000	ECX	WL	RN2786V	PN53013	RN2787V	PN53017
06.21~	3600	ERC	WL	RN2788V RN2786V	PN53013 PN53018	RN2789 RN2787V	PN53017 PN53020
06.21~	5700	EZH	WL	RN2786V	PN53013	RN2787V	PN53017
