NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2787V

Product
Application

ROTOR DISC » RN2787V

Specification

Type

Vented

Outter Ø

350

Num. of holes

5

Hole Ø:

17

Disc Thickness (Max)

22

Disc Thickness (Min)

20

Height

41

Centering Diameter

72

Pitch Circle Ø

127

Drum Ø:

173

Front/Rear

Rear

Structure Material

G3000

Cross Reference

CHRYSLER

68341 651AA

CHRYSLER

68341 651AB

CHRYSLER

68463 428AA

CHRYSLER

68463 428AB

HI-Q

SD5976

years	Eng	Eng No	BodyBody	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

JEEP » Grand Cherokee

05.21~	2000	EC1	WL	RN2788V RN2786V	PN53018 PN53013	RN2787V RN2789	PN53020 PN53017
05.21~	2000	ECX	WL	RN2786V	PN53013	RN2787V	PN53017
06.21~	3600	ERC	WL	RN2788V RN2786V	PN53013 PN53018	RN2789 RN2787V	PN53017 PN53020
06.21~	5700	EZH	WL	RN2786V	PN53013	RN2787V	PN53017
