NiBK Brakes:: Application Cross Reference and Image for NiBK : ROTOR DISC : RN2810V

ROTOR DISC » RN2810V

Image Not Available

Specification

Type

Vented

Outter Ø

345

Num. of holes

5

Hole Ø:

14.6

Disc Thickness (Max)

30

Disc Thickness (Min)

28

Height

56.7

Centering Diameter

69

Pitch Circle Ø

114.3

Drum Ø:

160

Front/Rear

Front

Structure Material

G3000

Cross Reference

HYUNDAI / KIA

51712-T1100

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

GENESIS » GV70

12.20~01.25	2500	G4KR	R21 LHD GCC	RN2810V	PN6135	RN2811	PN6141
03.21~	2500	G4KR	R21 LHD US	RN2810V	PN6135 PN6158	RN2811	PN6141
03.21~	2500	G4KR	R21 RHD	RN2810V	PN6158 PN6135	RN2811	PN6141
