ROTOR DISC » RN1345V

RN1345V

Specification

Type
Vented
Disc Thickness (Max)
20
Num. of holes
4
Height
41.7
Centering Diameter
74
Front/Rear
Front
Outter Ø
255

Cross Reference

BENDIX
561440B
TOYOTA
43512-28050
TOYOTA
43512-28051
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Lite/Townace

11.82~10.96 2000 2C CR21G RN1345VRN1533VRN1342VRN1336V PN1328PN1404 FN2232FN2220FN2252
08.85~08.88 2000 2C-T CR21G RN1336VRN1345VRN1533VRN1342V PN1328PN1404 DN1243 FN2220FN2232
08.87~01.92 2000 2C-T CR28G RN1336VRN1345VRN1533V PN1328PN1404 DN1243 FN2232FN2220

TOYOTA   »   Liteace

09.85~01.92 1800 1C CM35RV RN1345V PN1328 FN2232
09.85~01.92 1800 2Y-U YM30G RN1345V PN1328 FN2232

TOYOTA   »   Masterace

05.83~01.92 2000 3Y-EU YR21G RN1342VRN1345V PN1328 FN2220
