BRAKE SHOE » FN2252
Specification
Radius
127
Width
50
Thickness
5/7.2
Pcs In Set
4
Cross Reference
AKEBONO
NR-1048
AKEBONO
NR-1055
BENDIX AUS
BS1492
BENDIX EUR
361341B
BENDIX EUR
361403B
DAIHATSU
04495-26091-000
DAIHATSU
04495-28061-000
FMSI
S505-1358
KASHIYAMA
K-2282A
KASHIYAMA
K2252
KASHIYAMA
K2282
KASHIYAMA
K2283
TOYOTA
04047-26050
TOYOTA
04047-26051
TOYOTA
04047-26060
TOYOTA
04047-28040
TOYOTA
04047-30050
TOYOTA
04047-30061
TOYOTA
04495-25060
TOYOTA
04495-25150
TOYOTA
04495-26041
TOYOTA
04495-26080
TOYOTA
04495-26090
TOYOTA
04495-26091
TOYOTA
04495-26110
TOYOTA
04495-26111
TOYOTA
04495-26120
TOYOTA
04495-26121
TOYOTA
04495-27060
TOYOTA
04495-28040
TOYOTA
04495-28041
TOYOTA
04495-28050
TOYOTA
04495-28051
TOYOTA
04495-28060
TOYOTA
04495-28061
TOYOTA
04495-28071
TOYOTA
04495-30050
TOYOTA
04495-30051
TOYOTA
04495-30060
TOYOTA
04495-30070
TOYOTA
04495-30071
TOYOTA
04495-30072
TOYOTA
04495-30073
TOYOTA
04495-30080
TOYOTA
04495-30081
TOYOTA
04495-30090
TOYOTA
04495-35060
TOYOTA
04495-35061
TOYOTA
04495-35130
TOYOTA
04495-35131
TOYOTA
04495-35160
TOYOTA
04495-35170
TOYOTA
04495-40020
TOYOTA
04495-40021
TOYOTA
04495-43060
TOYOTA
04495-60040
TOYOTA
04495-60041
TOYOTA
04497-26050
TOYOTA
04497-26051
TOYOTA
04497-26060
TOYOTA
04497-26061
TOYOTA
04497-28041
TOYOTA
04497-30051
TOYOTA
04497-30062
TOYOTA
04497-30070
TOYOTA
47620-30110
years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
---|
08.83~08.87 | 2000 | GS126V | PN1052 | FN2252 | FN21001 | |||
09.87~04.99 | 2000 | GS130G | PN1157 | FN2252 | ||||
09.87~04.99 | 2000 | GS130H | PN1157 | FN2252 | ||||
08.83~08.87 | 2000 | MS120 | PN1052 | FN2252PN1142 | FN21001 | |||
09.87~04.99 | 2000 | MS130 | PN1157 | FN2252 | ||||
08.83~08.87 | 2000 | YS120 | FN2251PN1052 | FN2252 | ||||
12.91~12.95 | 2000 | YS130 | PN1157 | FN2252 | ||||
08.83~08.88 | 2000 | 1G-EU | GS120 | PN1052 | RN1488V | PN1142FN2252 | ||
08.83~08.87 | 2000 | 1G-EU | GS120G | PN1052 | FN2252 | FN21001 | ||
09.88~12.95 | 2000 | 1G-FE | GS130 | RN1828V | PN1157 | PN1142FN2252 | ||
12.95~09.98 | 2000 | 1G-FE | GS130W | RN1828V | PN1157 | FN2252 | ||
08.89~04.99 | 2000 | 1G-FE | GS136V | RN1828V | PN1157 | FN2252 | ||
08.83~08.87 | 2400 | LS120 | PN1052FN2251 | PN1142FN2252 | ||||
08.83~08.87 | 2400 | LS120G | PN1052 | FN2252 | ||||
08.83~08.87 | 2400 | LS126V | PN1052 | FN2252 | ||||
09.87~09.94 | 2400 | 2L | LS136V | PN1157 | FN2252 | |||
08.93~04.99 | 2400 | 2L-TE | LS130W | RN1828V | PN1157 | FN2252 | ||
08.90~04.99 | 2500 | 1JZ-GE | JZS130G | RN1490V | PN1157 | FN2252 |
12.95~07.01 | 2000 | 1G-GPE | GXS10 | RN1301V | PN1246 | DN1265DN1266 | FN2333FN2252FN2363 | |
12.95~07.01 | 2000 | 3Y-PE | YXS10 | RN1301V | PN1246 | DN1265DN1266 | FN2252FN2363FN2333 | |
12.95~07.01 | 2000 | 3Y-PE | YXS11 | RN1301V | PN1246 | DN1265DN1266 | FN2252FN2363FN2333 | |
12.95~08.08 | 2000 | 3Y-PE | YXS11Y | RN1301V | PN1246 | DN1265 | FN2232FN2252FN2363FN2333 | |
01.95~06.07 | 2400 | 2L-TE | LXS11 | RN1301V | PN1246 | FN2252FN2333FN2363 | ||
12.95~08.99 | 2400 | 2L-TE | LXS11 | RN1301V | PN1246 | DN1265 | FN2333FN2252 | |
05.98~08.01 | 3000 | 5L | LXS12 | RN1301V | PN1246 | DN1265 | FN2252 |
01.92~04.94 | 2200 | 3C-T | CXR10G | RN1532V | PN1273 | DN1256 | FN2252FN2335 | |
01.92~01.99 | 2200 | 3C-T | CXR11G | RN1532V | PN1273 | RN1099V | FN2252PN1274 | FN0567 |
01.92~05.94 | 2200 | 3C-T | CXR20G | RN1070VRN1532VRN1461V | PN1273PN1404PN1217 | RN1099VDN1256 | FN2335FN2252PN1274 | FN0567 |
01.92~05.94 | 2200 | 3C-T | CXR21G | RN1532VRN1461V | PN1404PN1217PN1273 | RN1099V | PN1274FN2252FN2335 | FN0567 |
08.93~04.94 | 2200 | 3C-TE | CXR11G | PN1273 | FN2335FN2252 | |||
01.92~04.94 | 2400 | 2TZ-FE | TCR10G | RN1070VRN1532V | PN1217PN1404PN1273 | DN1256RN1099V | PN1274FN2335FN2252 | |
01.92~04.94 | 2400 | 2TZ-FE | TCR11G | RN1461VRN1070V | PN1217PN1273PN1404 | RN1099V | FN2335FN2252PN1274 | FN0567 |
01.92~05.94 | 2400 | 2TZ-FE | TCR20G | RN1070VRN1461VRN1532V | PN1404PN1217PN1273 | RN1099VDN1256 | FN2335PN1274FN2252 | FN0567 |
01.92~05.94 | 2400 | 2TZ-FE | TCR21G | RN1070VRN1461VRN1532V | PN1217PN1273PN1404 | RN1099V | FN2335PN1274FN2252 | FN0567 |
12.82~08.89 | 2000 | 3Y | YH51G | RN1026V | PN1166 | FN2252 | ||
01.84~08.89 | 2400 | 2L | LH61G | PN1166 | FN2252 | |||
08.87~08.89 | 2400 | 2L | LH71G | PN1166 | FN2252 | |||
01.84~08.89 | 2400 | 2L# | LH51G | RN1026V | PN1166 | FN2252 |
08.97~08.05 | 2000 | 1RZ-E | RZN142L | RN1026V | PN1166 | DN1215DN1209 | FN2330FN2252 | |
08.97~03.06 | 2000 | 1RZ-E | RZN147 | RN1026V | PN1227 | DN1209DN1215 | FN2252FN2330 | |
08.97~08.05 | 2000 | 1RZ-E | RZN147L | RN1026V | PN1166 | DN1209DN1215 | FN2252FN2330 | |
08.99~08.03 | 2000 | 1RZ-E | RZN152H | RN1026V | PN1227 | DN1215 | FN2252 | |
08.85~08.05 | 2400 | 2L | LN145R | RN1475VRN1026V | PN1830PN1166 | DN1209DN1215 | FN2330FN2252 | |
08.83~03.89 | 2400 | 2L | LN56L | PN1071 | DN1215 | FN2252 | ||
08.01~08.05 | 2500 | 2KD-FTV | KDN145 | RN1475V | PN1166PN1830 | DN1215 | FN2252 | |
08.97~02.05 | 2700 | 3RZ-F | RZN149R | RN1026V | PN1166 | DN1215DN1209 | FN2252FN2330 | |
08.97~11.05 | 2700 | 3RZ-FE | RZN144L | RN1026V | PN1166 | DN1215 | FN2252 | |
08.97~03.06 | 3000 | 5L-E | LN147 | RN1026V | PN1227 | DN1215 | FN2252 |
06.84~12.96 | 2400 | 22R | RJ70L | RN1823 | PN1086PN1387 | FN2252 | ||
06.84~12.96 | 2400 | 22R | RJ70R | RN1823 | PN1086PN1387 | FN2252 | ||
09.90~04.94 | 2400 | 22R | RJ73 | PN1219PN1242 | FN2252FN2305PN1243 | |||
09.90~04.94 | 2400 | 22R | RJ73LV | PN1219 | FN2252PN1243 | |||
10.85~09.96 | 2400 | 2L-T | LJ73LV | RN1823RN1139V | PN1086PN1387PN1219PN1350 | FN2252PN1243 |
10.85~01.90 | 2400 | 2L-T | LJ71G | RN1823 | PN1086 | FN2252 | ||
11.84~05.93 | 2400 | 2LT | LJ70 | RN1823RN1139V | PN1219PN1086 | RN1216V | PN1243FN2252FN2305 | FN0642 |
10.85~01.92 | 2000 | 2C | CM41V | PN1217 | FN2252 | |||
11.82~10.96 | 2000 | 2C | CR21G | RN1345VRN1533VRN1342VRN1336V | PN1404PN1328 | FN2232FN2220FN2252 | ||
01.92~10.96 | 2000 | 2C | CR36V | PN1218 | FN2252 | |||
01.92~09.93 | 2000 | 2C-T | CR37G | PN1218 | FN2252 | |||
01.92~10.96 | 2000 | 3Y-EU | YR30G | PN1218 | FN2252 | |||
09.93~10.96 | 2200 | 3C-T | CR22G | RN1533V | PN1404PN1328 | DN1255DN1243 | FN2232FN2252 | |
09.93~10.96 | 2200 | 3C-T | CR29G | RN1533V | PN1328PN1404 | DN1243 | FN2252FN2232 | |
09.93~10.96 | 2200 | 3C-T | CR31G | PN1218 | FN2252 | |||
09.93~10.96 | 2200 | 3C-T | CR38G | PN1218 | FN2252 |
10.86~06.99 | 1800 | 2Y | YM60 | PN1217 | FN2252 | |||
08.90~06.99 | 1800 | 2Y | YM65 | PN1217 | FN2252 | |||
10.86~06.99 | 2000 | 2C | CM60 | PN1217 | FN2252 | |||
10.86~06.99 | 2000 | 2C | CM65 | PN1217 | FN2252 |
10.85~01.92 | 2000 | 2C-T | CM40G | PN1217 | FN2252 | |||
01.92~09.93 | 2000 | 2C-T | CR30G | PN1218 | FN2252 | |||
10.85~01.92 | 2000 | 3Y-U | YM40G | PN1217 | FN2252 |
10.85~01.92 | 2000 | 2C-T | CR30G | PN1218 | FN2252 | |||
10.85~01.92 | 2000 | 2C-T | CR37G | PN1218 | FN2252 | |||
10.85~01.92 | 2000 | 3Y-EU | YR30G | PN1218 | FN2252 | |||
10.85~01.92 | 2000 | 3Y-EU | YR36G | PN1218 | FN2252 |
01.90~04.94 | 2400 | 2TR-FE | TCR21R | PN1217 | FN2335PN1274FN2252 | FN0567 | ||
01.90~04.94 | 2400 | 2TZ-FE | TCR10L | RN1461VRN1532VRN1070V | PN1217PN1273 | DN1256RN1099V | FN2252FN2335PN1274 | FN0567 |
05.90~12.99 | 2400 | 2TZ-FE | TCR11L | RN1070V | PN1404PN1273PN1217 | FN2252PN1274 | FN0567 | |
01.90~05.94 | 2400 | 2TZ-FE | TCR20L | RN1532VRN1461VRN1070V | PN1404PN1273PN1217 | DN1256RN1099V | PN1274FN2252FN2335 | FN0567 |
01.90~04.94 | 2400 | 2TZ-FE | TCR20R | RN1070V | PN1217PN1404PN1273 | DN1256 | FN2252FN2335PN1274 | FN0567 |
05.90~04.94 | 2400 | 2TZ-FE | TCR21L | PN1404PN1273 | PN1274FN2335FN2252 | FN0567 | ||
01.90~04.94 | 2400 | 2TZ-FZE | TCR10L | RN1070V | PN1404PN1273 | DN1256 | FN2335PN1274FN2252 | FN0567 |
