ROTOR DISC » RN1490V

RN1490V

Specification

Type
Vented
Disc Thickness (Max)
26
Num. of holes
5
Height
38
Centering Diameter
76
Front/Rear
Front
Outter Ø
280
Pitch Circle Ø
100

Cross Reference

TOYOTA
43512-30220
TOYOTA
43512-30260
TOYOTA
4351230160
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Crown

08.93~07.95 2000 1G-FE GS141 RN1490V PN1157 PN1142 FN21001
01.91~12.95 2400 2L-THE LS141 RN1490V PN1157 PN1142 FN21001
08.90~04.99 2500 1JZ-GE JZS130G RN1490V PN1157 FN2252
10.91~12.95 3000 2JZ-GE JZS133 RN1490V PN1157 PN1142 FN21001
10.91~12.95 3000 2JZ-GE JZS133L RN1490V PN1157 PN1142 FN21001
01.88~11.01 3000 2JZ-GE JZS133R RN1490V PN1157 PN1142 FN21001
08.89~10.91 4000 1UZ-FE UZS131 RN1490V PN1157 PN1142

TOYOTA   »   Crown Majesta

10.91~08.95 2500 1JZ-GE JZS141 RN1490V PN1157 PN1142 FN21001
