DRUM BRAKE » DN1204

Specification

Outter Ø
303
Num. of holes
5
Hole Ø
14.4
Centering Diameter
62
Height
73.8
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-0K100
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.03~07.11 2000 1TR-FE TGN40L RN1340V PN1801 DN1204 FN2335
08.04~11.16 2000 1TR-FE TGN40R RN1627VRN1340V PN1802PN1831PN1801 DN1204 FN2335
01.05~03.16 2500 2KD-FTV KUN40L RN1340V PN1801 DN1204 FN2335
08.04~03.16 2500 2KD-FTV KUN40R RN1340VRN1942V PN1831 DN1204 FN2335

Exemption from liability: the catalog data is advisory and can be used for reference only
