DRUM BRAKE » DN1205

DN1205

Specification

Outter Ø
303
Num. of holes
5
Hole Ø
14.5
Centering Diameter
62
Height
73.6
Pitch Circle Ø
114.3
Drum Ø
254
Structure Material
G3000

Cross Reference

TOYOTA
42431-0K190
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

TOYOTA   »   Innova

07.16~ 2000 1TR-FE TGN140L RN2397V PN1803 DN1205 FN2402
11.15~ 2700 2TR-FE TGN141L RN2397V PN1803 DN1205 FN2402
04.16~ 2800 1GD-FTV GUN143L RN2397V PN1803 DN1205 FN2402
