ROTOR DISC » RN1319V

Specification

Type
Vented
Disc Thickness (Max)
25
Num. of holes
6
Height
68
Centering Diameter
108
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
297
Drum Ø:
170
Disc Thickness (Min)
23
Structure Material
G3000

Cross Reference

TOYOTA
43512-0K060
TOYOTA
43512-0K070
TOYOTA
43512-0K080
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
01.05~04.12 2500 2KD-FTV KUN50 RN1319V PN1482PN1830 FN0620
01.05~04.16 2500 2KD-FTV KUN60L RN1319V PN0548PN1482PN1830 FN0620
01.05~07.11 2700 2TR-FE GGN60 RN1319V PN1482 FN0620
06.06~07.11 2700 2TR-FE KUN6 RN1319V PN1482 FN0620
01.05~04.12 2700 2TR-FE TGN51L RN1319V PN1830PN1482 FN0620
01.05~08.07 2700 2TR-FE TGN51R RN1319V PN1830 FN0620
01.05~ 2700 2TR-FE TGN61R RN1319V PN0548PN1482PN1830 FN0620
01.05~07.11 2700 2TR-FE TGN65 RN1319V PN1482 FN0620
01.05~08.08 3000 1KD-FTV KUN51R RN1446VRN1664VRN1319V PN1482PN1830 FN0620
05.06~11.13 3000 5L-E LAN50R RN1319V PN1482 FN0620
02.05~12.15 4000 1GR-FE GGN50R RN1319V PN1482 FN0620
05.15~ 2400 2GD-FTV GUN125R RN1664VRN1319V PN1482PN0548 DN1102 FN0620
01.15~ 2500 2KD-FTV KUN122L RN1319VRN1627V PN1803 DN1203 FN2402FN2335
05.15~07.17 2500 2KD-FTV KUN125R RN1319VRN1664V PN0548PN1482 DN1102 FN0620
02.05~12.15 2500 2KD-FTV KUN25L RN1319V PN0548PN1482PN1830 DN1102 FN0620
03.05~01.16 2500 2KD-FTV KUN25R RN1319VRN1664V PN0548PN1830PN1482 DN1102 FN0620
01.05~10.15 2500 2KD-FTV KUN35L RN1319V PN1830 FN0620
07.11~ 2500 2KD-FTV KUN35R RN1319V PN0548 DN1102 FN0620
11.15~ 2700 2TR-FE TGN126L RN1664VRN1319VRN1446V PN0548PN1482 DN1102 FN0620
01.21~ 2700 2TR-FE TGN127L RN1664VRN1446VRN1319V PN1482PN0548 DN1102 FN0620
07.16~ 2700 2TR-FE TGN128L RN1446VRN1664VRN1319V PN1482PN0548 DN1102 FN0620
08.04~12.08 2700 2TR-FE TGN26L RN1319V PN1830 DN1102 FN0620
01.04~01.18 2700 2TR-FE TGN36L RN1319VRN1664V PN0548PN1830PN1482 FN0620
04.05~01.19 2700 2TR-FE TGN36L RN1319V PN1830PN0548 FN0620
01.04~01.18 2700 2TR-FE TGN36R RN1319VRN1446V PN0548PN1482 DN1102 FN0620FN2305
08.04~08.13 3000 1KD-FTV KUN26R RN1664VRN1319V PN0548PN1482PN1830 DN1102 FN0620
01.04~10.11 3000 1KD-FTV KUN36L RN1319V PN1482PN1830 DN1102 FN0620
05.04~10.08 3000 1KD-FTV KUN36R RN1446VRN1319V PN1830PN0548 DN1102 FN0620
07.05~12.15 3000 5L-E LAN25L RN1319V PN1830PN0548PN0828 FN0620
04.01~10.13 3000 5L-E LAN25R RN1319V PN0548PN1830PN0828 DN1102 FN0620
08.11~10.13 3000 5L-E LAN25R RN1319V PN0548 FN2305FN0620
05.05~10.13 3000 5L-E LAN35R RN1319V PN0548PN1830 DN1102 FN0620FN2305

Exemption from liability: the catalog data is advisory and can be used for reference only
