NiBK Brakes:: Application Cross Reference and Image for NiBK : DRUM BRAKE : DN1212

DRUM BRAKE » DN1212

Specification

Outter Ø

282

Num. of holes

5

Hole Ø

14.8

Centering Diameter

62.1

Height

71.2

Pitch Circle Ø

114.3

Drum Ø

228.5

Structure Material

G3000

Cross Reference

TOYOTA

42431-06010

TOYOTA

42431-06040

TOYOTA

42431-06100

TOYOTA

42431-33020

TOYOTA

42431-33110

TOYOTA

42431-33111

years	Eng	Eng No	Body	Front Rotor	Front Brake	Rear Rotor	Rear Brake	Parking Shoe

TOYOTA » Camry

08.01~11.06

2400

2AZ-FE

ACV30L

RN1009V

PN1479

DN1212 RN1486

PN1458 FN2406 FN2333

FN0633

TOYOTA » Solara coupe (USA)

06.98~07.01	2200	5S-FE	SXV20L	RN1009V	PN1401	DN1212	FN2333
07.01~12.02	2400	2AZ-FE	ACV20L	RN1009V	PN1401	DN1212	FN2333
