DRUM BRAKE » DN1425

DN1425

Specification

Outter Ø
372
Num. of holes
6
Centering Diameter
144
Height
130.5
Drum Ø
320
Structure Material
G3000
Hole Ø
15
Pitch Circle Ø
199

Cross Reference

HINO
43512-37130
TOYOTA
43512-37130
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

HINO   »   DUTRO

07.11~ 4000 N04C-T XZU720R DN1425RN2251V FN0646PN4464 DN1424RN2252V
10.06~06.11 4000 N04C-UV WU422L DN1424 FN0646 DN1425 FN0802

HINO   »   Dutro WU-720

01.12~ 4000 W04D WU720L DN1425 FN0646 DN1424 FN0802 FN2320

TOYOTA   »   Dyna

07.11~ 4000 N04C-T XZU710L RN2251VDN1425RN1448V FN2329PN4464BL2329FN0646PN1388 DN1424RN1841VRN2252VDN1217 FN0802FN2329 FN2320
10.01~02.08 4000 W04D WU410 DN1425 FN0646 DN1424
10.01~02.08 4000 W04D WU410R DN1425 FN0646 DN1424 FN0802 FN2320
05.99~06.04 4100 15B-FTE BU430 DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~10.06 4900 S05D XZU401 DN1425RN2251VRN1448V PN1388PN4464FN0646 DN1217RN2252VDN1424 BL2329FN2296FN2329PN4464 FN0015FN2320
05.99~06.04 5300 J05C XZU330 RN1448VDN1425 PN1388FN0646 DN1217 FN2329BL2329 FN4443FN0015FN2320
05.99~06.04 5300 J05C XZU340 DN1425RN1448V FN0646PN1388 DN1424DN1217 FN2329BL2329 FN0039FN2320FN0015
05.99~06.04 5300 J05C XZU350H DN1425 FN0646 DN1424 FN2329BL2329 FN2320FN4443
05.99~06.04 5300 J05C XZU400A DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~06.04 5300 J05C XZU410 RN1448VDN1425 FN0646PN1388 DN1217DN1424 BL2329FN2329 FN2320
05.99~06.04 5300 J05C XZU420 DN1425 FN0646 DN1424 FN2329BL2329 FN2320
05.99~02.08 5300 J05C XZU430 DN1425 FN0646 DN1424 FN2329BL2329 FN2320
