DRUM BRAKE » DN1585

DN1585

Specification

Outter Ø
298
Num. of holes
5
Hole Ø
13.3
Centering Diameter
71.1
Height
107.1
Pitch Circle Ø
108
Drum Ø
254
Structure Material
G3000

Cross Reference

CITROEN
4247 56
FIAT
1400178980
FIAT
1400363380
FIAT
1401417180
FIAT
6001073061
Peugeot / Citroen
4247 51
Peugeot / Citroen
4247 56
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CITROEN   »   Jumpy

07.07~03.16 1600 DV6UTED4 RN1858V PN0531W DN1585RN1851 PN0534FN0546

FIAT   »   Scudo

01.07~03.16 1600 DV6UTED4 272 RN1858V PN0531W DN1585 FN0546
