ROTOR DISC » RN1858V

RN1858V

Specification

Type
Vented
Outter Ø
280
Num. of holes
5
Disc Thickness (Max)
28
Height
48
Centering Diameter
71
Pitch Circle Ø
108
Front/Rear
Front
Disc Thickness (Min)
26
Drum Ø:
152

Cross Reference

CITROEN
4249.87
CITROEN
4249.J9
CITROEN
424921
CITROEN
9467548387
FIAT
1401416880
FIAT
9404249878
PEUGEOT
4249.J9
PEUGEOT
424920
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

CITROEN   »   Jumpy

07.07~03.16 1600 DV6UTED4 RN1858V PN0531W DN1585RN1851 PN0534FN0546
07.07~03.16 2000 DW10BTED4 RN1858V PN0531W PN0534

FIAT   »   Scudo

01.07~03.16 1600 DV6UTED4 272 RN1858V PN0531W DN1585 FN0546
01.07~ 2000 DW10BTED4 270 RN1858V PN0531W PN0534
01.07~01.16 2000 RHK40 272.4L2.0.0 RN1858VRN1850V PN0531W RN1851 PN0534
01.07~01.16 2000 RHK40 272.4V2.0.0 RN1858VRN1850V PN0531W RN1851 PN0534
01.07~01.16 2000 RHK40 272.6E2.0.0 RN1858VRN1850V PN0531W RN1851 PN0534
01.07~01.16 2000 RHR40 272.6E3.0.0 RN1850VRN1858V PN0531W RN1851 PN0534

PEUGEOT   »   Expert II

01.07~04.16 2000 DW10BTED4 RN1858V PN0531W PN0534

TOYOTA   »   Proace

06.13~ 1600 3WZ-FTV DV6 RN1850VRN1858V PN0531W RN1851 PN0534
