ROTOR DISC » RN1629V

Specification

Type
Vented
Outter Ø
304
Num. of holes
10
Disc Thickness (Max)
30
Height
108.3
Centering Diameter
150
Pitch Circle Ø
181
Front/Rear
Front
Hole Ø:
M10x1.25
Disc Thickness (Min)
28
Structure Material
G3000

Cross Reference

HYUNDAI
51761-45020
HYUNDAI
51761-45021
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
03.98~01.08 3300 D4AL HD17LP BUS DOM RN1629V PN0417 FN11003FN0635 FN6600
01.04~01.10 3900 D4DD HD17PP RN1629V PN0417 FN4443

Exemption from liability: the catalog data is advisory and can be used for reference only
