ROTOR DISC » RN1536VSET

RN1536VSET

Specification

Type
Vented
Outter Ø
296
Num. of holes
5
Disc Thickness (Max)
32
Height
50.8
Centering Diameter
62
Pitch Circle Ø
114.3
Disc Thickness (Min)
30
Drum Ø:
142.6
Structure Material
G3000

Cross Reference

TOYOTA
43512-30320R
TOYOTA
43516-30010L
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe

LEXUS   »   IS250

08.05~04.13 2500 4GR-FSE GSE25 RN1258VRN1536VRN1536VSET PN1479PN1829 RN1438 PN1494 FN0659

TOYOTA   »   Crown Majesta

12.03~02.08 2500 4GR-FSE GRS180 RN1536VRN1258VRN1536VSET PN1550PN1479 RN1665V PN1494

TOYOTA   »   Mark X

11.04~09.09 2500 4GR-FSE GRX120 RN1536VSETRN1258VRN1536V PN1479PN1550 RN1438RN1665V PN1494 FN0659
