ROTOR DISC » RN1997V

Specification

Type
Vented
Outter Ø
350
Num. of holes
5
Disc Thickness (Max)
32
Height
43.7
Centering Diameter
69
Pitch Circle Ø
114.3
Drum Ø:
160
Front/Rear
Front

Cross Reference

MITSUBISHI
4615A023
MITSUBISHI
4615A024
MITSUBISHI
4615A184
MITSUBISHI
4615A185
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
08.07~03.16 2000 4B11-T CZ4A RN1997VRN1403V PN0150WPN0150S RN2004V PN23002 FN0625
10.07~03.16 2000 4B11 CZ4A RN1997V PN0150WPN0150SPN3233 RN2004V PN23002 FN0625
10.07~03.16 2000 4B11 CZ4A RN1997V PN0150SPN0150WPN3233 RN2004V PN23002 FN0625

Exemption from liability: the catalog data is advisory and can be used for reference only
