ROTOR DISC » RN2004V

Specification

Type
Vented
Outter Ø
330
Num. of holes
5
Disc Thickness (Max)
22
Height
58.3
Centering Diameter
80
Pitch Circle Ø
114.3
Drum Ø:
189
Front/Rear
Rear
Structure Material
G3000

Cross Reference

BENDIX
PRT6069
MITSUBISHI
4615A025
MITSUBISHI
4615A186
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
10.07~03.16 2000 4B11 CY4A RN1403V PN3233 RN2004V PN3450 FN0625
08.07~03.16 2000 4B11-T CZ4A RN1997VRN1403V PN0150WPN0150S RN2004V PN23002 FN0625
10.07~03.16 2000 4B11 CZ4A RN1997V PN3233PN0150WPN0150S RN2004V PN23002 FN0625
10.07~03.16 2000 4B11 CZ4A RN1997V PN3233PN0150SPN0150W RN2004V PN23002 FN0625

Exemption from liability: the catalog data is advisory and can be used for reference only
