ROTOR DISC » RN1223

Specification

Type
Solid
Disc Thickness (Max)
10
Num. of holes
5
Height
64.9
Centering Diameter
62
Pitch Circle Ø
114
Front/Rear
Rear
Outter Ø
287.6
Drum Ø:
170
Disc Thickness (Min)
9
Structure Material
G3000

Cross Reference

TOYOTA
42431-06070
TOYOTA
42431-33030
TOYOTA
42431-48030
TOYOTA
4243106030
TOYOTA
4243133050
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
07.01~03.06 3000 1MZ-FE MCV30R RN1162V PN1479PN1480 RN1223 PN1458 FN0633
01.98~02.03 3000 1MZ-FE MCU10 RN1162V PN1481 RN1223 PN1321 FN0633
08.01~01.06 2000 1AZ-FE ACV31L RN1009V PN1479 RN1486RN1223 PN1458 FN0633
08.01~01.06 2000 1AZ-FE ACV31R RN1009V PN1479 RN1223 PN1458 FN0633
01.91~09.01 2200 5S-FE SXV10 RN1009V PN1322 RN1223 PN1321
06.91~01.02 2200 5S-FE SXV20L RN1009VRN1008V PN1322PN1228PN1401 RN1486RN1223 FN2333PN1321PN1431 FN0633
06.91~01.02 2200 5S-FE SXV20R RN1008VRN1009V PN1228PN1401PN1322 RN1486RN1223 PN1431PN1321 FN0633
08.01~11.06 3000 1MZ-FE MCV30L RN1162V PN1479 RN1223 PN1458 FN0633
12.97~11.07 2200 5S-FE SXU10W RN1162V PN1481PN1401 RN1223 PN1321 FN0633
12.97~02.03 2400 2AZ-FE ACU10W RN1162V PN1481PN1401 RN1223 PN1321 FN0633
12.97~02.03 3000 1MZ-FE MCU10W RN1162V PN1481PN1401 RN1223 PN1321PN1458 FN0633
01.00~08.03 2400 2AZ-FE ACU20W RN1442V PN1457 RN1255RN1223 PN1498PN1458 FN0567FN0633
07.92~07.96 3000 3VZ-FE VCV15W RN1009V PN1228 RN1223 PN1321 FN0633
08.93~08.96 2500 4VZ-FE VCV11 RN1009V PN1228 RN1223 PN1321 FN0633

Exemption from liability: the catalog data is advisory and can be used for reference only
