BRAKE SHOE » FN0686

Specification

Radius
147.5
Width
50
Thickness
4.5 / 8.5
Pcs In Set
4

Cross Reference

FMSI
S764-1397
TOYOTA
04495-35220
TOYOTA
04495-35250
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
09.06~12.09 4600 LH2 PN0669 FN0686PN0625
05.05~12.07 3600 LY7 PN51005 FN0686PN51004
09.07~12.10 4600 LH2 PN51005 PN51004FN0686
11.95~08.02 3400 5VZ-FE VZN180L RN1830VRN1128V PN1387PN1219 DN1214 FN2305FN0686
01.05~ 2500 2KD-FTV KDH222R RN1330V PN1516 DN1210DN1103DN1254 FN2378FN0686FN2305
01.94~01.04 2700 3RZ-FE RZN171 RN1830V PN1830PN1219 DN1214 FN2305FN0686
08.98~09.04 2700 3RZ-FE RZN191 RN1830V PN1830 DN1214 FN2305FN0686
02.98~09.04 2700 3RZ-FE RZN196 RN1830V PN1219PN1830 DN1214 FN0686FN2305
01.95~09.04 3400 5VZ-FE VZN170 RN1128VRN1830V PN1387PN1219PN1830 DN1214 FN0686FN2305
02.98~09.04 3400 5VZ-FE VZN195L RN1830V PN1387PN1830PN1219 DN1214 FN0686FN2305
02.99~08.04 3400 5VZ-FE VCK30 RN2354V PN1411PN1482 DN1213DN1214DN1253 FN0686FN2305
02.99~08.04 3400 5VZ-FE VCK40L RN2354V PN1411PN1482 DN1213DN1214DN1253 FN0686FN2305
08.04~08.06 4000 1GR-FE GSK30L RN2354V PN1482 DN1213 FN0686
02.99~12.06 4700 2UZ-FE UCK30L RN2354V PN1411PN1482 DN1213DN1214DN1253 FN2305FN0686
10.03~12.06 4700 2UZ-FE UCK31L RN2354V PN1482 DN1213 FN0686
02.99~12.06 4700 2UZ-FE UCK40 RN2354V PN1482PN1411 DN1214DN1253DN1213 FN2305FN0686
08.02~12.06 4700 2UZ-FE UCK41L RN2354V PN1482 DN1213 FN0686

Exemption from liability: the catalog data is advisory and can be used for reference only
