BRAKE SHOE » FN11005

Specification

Radius
95
Width
32
Thickness
6.0
Pcs In Set
4

Cross Reference

FMSI
S873-1546
HYUNDAI
58305-2BA00
HYUNDAI
58305-3LA00
HYUNDAI
58350-3AA10
HYUNDAI
58350-3EU00
SSANGYONG
4833A21000
SSANGYONG
4833A21010
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
02.05~12.11 3300 G6DB FC41 PN0377 PN0539 FN11005
09.05~12.11 2700 L6EA TG RN2193V PN0377 PN0539 FN11005
09.04~05.07 2500 D4CB WAGON LONG - 12P PN0103 PN0447 FN11005
03.02~09.04 2500 D4CB WAGON SHORT - 9P RN1951V PN0103 DN1481 PN0447FN11002 FN11005
12.05~07.09 2200 D4EB PCM 06 LHD RN2287V PN0446 RN2002 PN0447 FN11005
05.06~07.09 2700 G6EA CM RN1349VRN2287V PN0446 RN2002 PN0447 FN11005
01.06~08.09 2700 G6EA CM US RN2287V PN0446 RN2002 PN0447 FN11005
04.06~07.09 3300 G6DB CMA06 RN2287V PN0446 RN2002 PN0447 FN11005
04.06~07.09 3300 G6DB PCM06 RN2287V PN0446 RN2002 PN0447 FN11005
10.04~09.08 2000 G4GC MH81 RN1178V PN0103 RN1176 PN0539 FN11005
04.06~05.09 3300 G6DB PBL06 US PN0115 RN1197V PN0797 FN11005
04.06~05.09 3800 G6DA PBL06 US RN1313V PN0441PN0115 RN1197V PN0797PN0798 FN11005
01.05~01.15 2300 G23D 5DR SUV RN1620V PN0103 RN1657DN1689 PN0440FN1879 FN0696FN0750
01.05~01.15 2700 D27DT 5DR SUV RN1620V PN0103 RN1798VDN1689 PN0440FN1879 FN0696FN0750
01.12~10.17 2700 D27DT Y290 RN1620V PN0103 RN1798VRN1657 PN0797PN0440 FN0750FN0696
04.06~07.12 2700 D27DTP Y250 RN1620V PN0103 RN1798V PN0440PN0797 FN0750
09.04~02.13 2700 D27DT MPV -7P RN1456V PN0103 RN1749V PN0797 FN0750
05.07~07.13 3200 G32D MPV -11P RN1456V PN0103 RN2265V PN0797 FN0750
01.13~03.16 2000 D20DTR MPV -7P RN1456V PN0103 RN2265VRN1749V PN0797 FN0750
01.13~03.19 2000 D20DTR MPV -9P RHD RN1456V PN0103 RN1749VRN2265V PN0797 FN0750
01.13~03.16 3200 E32 MPV -7P RN1456V PN0103 RN1749VRN2265V PN0797 FN0750

Exemption from liability: the catalog data is advisory and can be used for reference only
