ROTOR DISC » RN1070V
Specification
Type
Vented
Disc Thickness (Max)
22
Num. of holes
5
Height
52.8
Centering Diameter
62
Front/Rear
Front
Pitch Circle Ø
114.3
Outter Ø
279
Disc Thickness (Min)
20
Drum Ø:
147
Structure Material
G3000
Cross Reference
BENDIX
562076B
TOYOTA
43512-28070
TOYOTA
43512-28080
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 08.93~12.99 | 2400 | 2TZ-FE | TCR10W | RN1070VRN1461V | PN1217PN1273PN1404 | RN1099V | PN1274 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR20W | RN1070V | PN1217PN1404PN1273 | RN1099VDN1256 | PN1274FN2252FN2335 | FN0567 |
| 01.92~12.98 | 2200 | 3C-T | CXR20G | RN1070VRN1532VRN1461V | PN1273PN1404PN1217 | RN1099VDN1256 | FN2335FN2252PN1274 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR10G | RN1070VRN1532V | PN1404PN1273PN1217 | DN1256RN1099V | PN1274FN2335FN2252 | |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR11G | RN1070VRN1461V | PN1273PN1217PN1404 | RN1099V | FN2252PN1274FN2335 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR20G | RN1070VRN1461VRN1532V | PN1273PN1404PN1217 | DN1256RN1099V | FN2335PN1274FN2252 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR21G | RN1070VRN1461VRN1532V | PN1217PN1273PN1404 | RN1099V | FN2335FN2252PN1274 | FN0567 |
| 05.90~12.99 | 2400 | 2TZ-FZE | TCR11W | RN1461VRN1070V | PN1404PN1217PN1273 | RN1099V | PN1274 | FN0567 |
| 08.94~12.99 | 2400 | 2TZ-FZE | TCR21W | RN1070VRN1461V | PN1273PN1404PN1217 | RN1099V | PN1274 | FN0567 |
| 01.90~12.99 | 2400 | 2TZ-FE | TCR10L | RN1461VRN1532VRN1070V | PN1217PN1273 | RN1099VDN1256 | PN1274FN2252FN2335 | FN0567 |
| 05.90~10.96 | 2400 | 2TZ-FE | TCR11L | RN1070V | PN1404PN1273PN1217 | FN2252PN1274 | FN0567 | |
| 01.90~08.94 | 2400 | 2TZ-FE | TCR20L | RN1532VRN1461VRN1070V | PN1404PN1273PN1217 | DN1256RN1099V | PN1274FN2252FN2335 | FN0567 |
| 01.90~04.94 | 2400 | 2TZ-FE | TCR20R | RN1070V | PN1217PN1404PN1273 | DN1256 | PN1274FN2252FN2335 | FN0567 |
| 01.90~08.96 | 2400 | 2TZ-FZE | TCR10L | RN1070V | PN1404PN1273 | DN1256 | FN2252FN2335PN1274 | FN0567 |
