ROTOR DISC » RN1532V
Specification
Type
Vented
Disc Thickness (Max)
25
Num. of holes
5
Height
53
Centering Diameter
62
Front/Rear
Front
Outter Ø
255
Hole Ø:
14.7
Pitch Circle Ø
114.3
Drum Ø:
145
Structure Material
G3000
Disc Thickness (Min)
23
Cross Reference
BENDIX
561748B
TOYOTA
43512-28060
TOYOTA
43512-28110
TOYOTA
43512-28111
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 01.92~12.99 | 2200 | 3C-T | CXR10G | RN1532V | PN1273 | DN1256 | FN2252FN2335 | |
| 01.92~01.99 | 2200 | 3C-T | CXR11G | RN1532V | PN1273 | RN1099V | FN2252PN1274 | FN0567 |
| 01.92~12.99 | 2200 | 3C-T | CXR20G | RN1532VRN1461VRN1070V | PN1273PN1404PN1217 | RN1099VDN1256 | FN2335FN2252PN1274 | FN0567 |
| 01.92~08.96 | 2200 | 3C-T | CXR21G | RN1532VRN1461V | PN1404PN1217PN1273 | RN1099V | FN2252FN2335PN1274 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR10G | RN1070VRN1532V | PN1217PN1404PN1273 | DN1256RN1099V | PN1274FN2335FN2252 | |
| 01.92~08.96 | 2400 | 2TZ-FE | TCR20G | RN1461VRN1532VRN1070V | PN1404PN1217PN1273 | DN1256RN1099V | PN1274FN2252FN2335 | FN0567 |
| 01.92~12.99 | 2400 | 2TZ-FE | TCR21G | RN1070VRN1461VRN1532V | PN1273PN1404PN1217 | RN1099V | PN1274FN2252FN2335 | FN0567 |
| 06.99~08.07 | 1800 | 7K-E | KM70/KM75 | RN1532VRN1534V | PN1404PN1273PN1405 | DN1243 | FN2339 | |
| 06.99~08.07 | 1800 | 7K-E | KM80 | RN1532V | PN1273PN1405 | FN2335 | ||
| 06.99~08.07 | 1800 | 7K-E | KM85 | RN1532V | PN1273PN1405 | DN1256 | FN2335 | |
| 06.99~08.04 | 2200 | 3C-E | CM80 | RN1532V | PN1405PN1273 | DN1256 | FN2335 | |
| 06.99~08.04 | 2200 | 3C-E | CM85 | RN1532V | PN1273PN1405 | FN2335 |
| 01.96~01.07 | 1800 | 7K-E | KR52V | RN1532V | PN1405 | DN1256 | FN2335 | |
| 11.96~12.98 | 2000 | 2C | CR51V | RN1532V | PN1405PN1273 | FN2335 | ||
| 10.96~12.98 | 2000 | 3S-FE | SR50G | RN1070VRN1532V | PN1273PN1405PN1404 | DN1256 | FN2335 | |
| 12.98~07.04 | 2200 | 3C-E | CR52V | RN1532V | PN1273PN1405 | FN2335 | ||
| 10.96~11.01 | 2200 | 3C-T | CR50G | RN1532V | PN1273PN1405 | FN2335 |
