ROTOR DISC » RN1823

Specification

Type
Vented
Outter Ø
302
Num. of holes
6
Disc Thickness (Max)
12.5
Height
48
Centering Diameter
100
Pitch Circle Ø
139.7
Front/Rear
Front
Drum Ø:
168
Disc Thickness (Min)
11.5
Structure Material
G3000
Hole Ø:
14.7

Cross Reference

TOYOTA
43512-35070
TOYOTA
43512-60060
TOYOTA
4351235060
years Eng Eng No Body Front Rotor Front Brake Rear Rotor Rear Brake Parking Shoe
11.83~08.88 2400 2L LN65 RN1823 PN1086FN2293 FN2260
06.84~12.96 2400 22R RJ70L RN1823 PN1387PN1086 FN2252
06.84~12.96 2400 22R RJ70R RN1823 PN1086PN1387 FN2252
10.85~09.96 2400 2L-T LJ73LV RN1823RN1139V PN1219PN1350PN1086PN1387 FN2252PN1243
10.85~01.90 2400 2L-T LJ71G RN1823 PN1086 FN2252
11.84~03.90 2400 2LT LJ70 RN1823RN1139V PN1086PN1219 RN1216V FN2305PN1243FN2252 FN0642

Exemption from liability: the catalog data is advisory and can be used for reference only
