ROTOR DISC » RN1139V
Specification
Type
Vented
Disc Thickness (Max)
20
Num. of holes
6
Height
47.9
Centering Diameter
100
Front/Rear
Front
Pitch Circle Ø
139.7
Outter Ø
302
Drum Ø:
167
Structure Material
G3000
Disc Thickness (Min)
19
Cross Reference
BENDIX
561444B
OEM
4351269040
TOYOTA
43512-35170
TOYOTA
43512-60011
TOYOTA
43512-60040
TOYOTA
43512-60041
TOYOTA
43512-60100
TOYOTA
43512-69015
TOYOTA
43512-69016
VOLKSWAGEN
J4351235170
| years | Eng | Eng No | Body | Front Rotor | Front Brake | Rear Rotor | Rear Brake | Parking Shoe |
|---|
| 09.88~08.91 | 2000 | 3Y | YN105 | RN1139V | PN1219PN1387 | DN1108 | FN2305 | |
| 01.88~12.97 | 2400 | 2L | LN105 | RN1139V | PN1219PN1387 | DN1108 | FN2305 | |
| 09.88~08.94 | 2800 | 3L | LN100 | RN1139V | PN1219PN1393PN1387 | DN1108 | FN2305 | |
| 09.88~08.97 | 2800 | 3L | LN106 | RN1139V | PN1219PN1387PN1393 | DN1108 | FN2305 | |
| 08.88~09.99 | 2800 | 3L | LN106L | RN1139V | PN1393PN1387PN1219 | DN1108 | FN2305 | |
| 08.88~09.99 | 2800 | 3L | LN106R | RN1139V | PN1219PN1387 | DN1108 | FN2305 |
| 04.90~04.96 | 2400 | 22R | RJ77 | RN1139V | PN1219PN0548 | DN1214 | FN2305 | |
| 10.85~09.96 | 2400 | 2L-T | LJ73LV | RN1823RN1139V | PN1350PN1086PN1387PN1219 | PN1243FN2252 | ||
| 01.85~12.96 | 2400 | 2L-T | LJ77L | RN1139V | PN1387PN1219 | DN1214 | FN2305 | |
| 01.90~12.96 | 2800 | 3L | LJ79RV | RN1139V | PN1219PN1387 | DN1214 | FN2305 | |
| 01.86~01.92 | 3000 | 1KZ-TE | KZJ71W | RN1139V | PN1350PN1086PN1219 | FN2283FN2280 | ||
| 01.60~01.01 | 3200 | 2B | BJ41V | RN1139V | PN1086PN1350FN2255 | FN2221 | FN2298 | |
| 10.85~01.90 | 3400 | 13B-T | BJ71V | RN1139V | PN1086 | DN1221 | FN2280 | |
| 10.85~02.90 | 3400 | 13B-T | BJ74RV | RN1139V | PN1086 | FN2280 | ||
| 11.84~02.92 | 3400 | 13B-T | BJ74V | RN1139V | PN1086 | FN2280 | ||
| 08.80~10.84 | 3400 | 3B | BJ42 | RN1139V | PN1350PN1086 | FN2280 | ||
| 01.81~12.92 | 3400 | 3B | BJ60RG | RN1139V | PN1350PN1086FN2296 | FN2280 | ||
| 08.80~12.92 | 3400 | 3B | BJ60V | RN1139V | FN2255PN1086PN1350 | FN2280 | ||
| 04.84~02.94 | 3400 | 3B | BJ75 | RN1139V | PN1387PN1086FN2296PN1350 | FN2280 | ||
| 11.84~01.90 | 3400 | 3B | BJ75LP | RN1139V | PN1086PN1350FN2296 | DN1221 | FN2280 | |
| 01.90~01.94 | 3500 | 1PZ | PZJ70V | RN1139V | PN1219PN1387 | DN1222 | FN2280 | |
| 01.86~01.92 | 3500 | 1PZ | PZJ77HV | RN1139V | PN1219PN1350PN1086 | FN2283FN2280 | ||
| 01.90~01.94 | 3500 | 1PZ | PZJ77HV | RN1139V | PN1387 | FN2280 | ||
| 04.90~01.94 | 3500 | 1PZ | PZJ77V | RN1139V | PN1387PN1219 | DN1222 | FN2280 | |
| 10.85~01.90 | 4000 | 12H-T | HJ61LG | RN1139V | PN1086PN1350 | FN2280 | ||
| 01.81~12.90 | 4000 | 12H-T | HJ61V | RN1139V | PN1350PN1086 | FN2280 | ||
| 08.80~01.90 | 4000 | 2H | HJ60LG | RN1139V | PN1086PN1350 | FN2280 | ||
| 01.81~12.90 | 4000 | 2H | HJ60R | RN1139V | PN1350PN1086 | DN1221 | FN2280 | |
| 01.81~12.90 | 4000 | 2H | HJ60V | RN1139V | PN1350PN1086 | DN1221 | FN2280 | |
| 08.87~01.90 | 4000 | 3F | FJ62LG | RN1139V | PN1350PN1086 | FN2280 | ||
| 08.80~09.87 | 4000 | 3F | FJ62V | RN1139V | PN1086PN1350 | DN1221 | FN2280 | |
| 08.88~01.90 | 4000 | 3F-E | FJ62G | RN1139V | PN1350PN1086 | DN1221 | FN2280 | |
| 01.94~08.99 | 4200 | 1H-Z | HZJ70 | RN1139V | PN1387PN1219 | DN1222 | FN2280 | |
| 01.94~08.99 | 4200 | 1H-Z | HZJ70V | RN1139V | PN1387PN1219 | DN1222 | FN2280 | |
| 01.90~08.99 | 4200 | 1H-Z | HZJ73HV | RN1139V | PN1387 | RN1157V | PN1243 | FN0642 |
| 01.90~12.01 | 4200 | 1H-Z | HZJ73V | RN1139V | PN1387PN1219 | DN1222RN1157V | PN1243FN2280 | FN0642 |
| 01.90~01.07 | 4200 | 1H-Z | HZJ75 | RN1139V | PN1219PN1387 | DN1222 | FN2280 | |
| 01.90~01.04 | 4200 | 1H-Z | HZJ75LV | RN1139V | PN1219PN1387FN2296 | DN1222 | FN2280 | |
| 04.90~08.99 | 4200 | 1H-Z | HZJ77HV | RN1139V | PN1219PN1387 | RN1157V | PN1243FN2280 | FN0642 |
| 01.95~08.99 | 4200 | 1H-Z | HZJ77V | RN1139V | PN1387PN1219 | DN1222 | FN2280 | |
| 10.82~11.84 | 4200 | 2F | FJ61V | RN1139V | PN1350PN1086 | DN1221 | FN2280 |
| 04.90~05.93 | 2400 | 2L-TE | LJ71G | RN1139V | PN1350 | RN1216V | PN1243 | FN0642 |
| 04.90~05.93 | 2400 | 2L-TE | LJ78G | RN1139V | PN1404PN1387 | RN1216V | PN1243 | FN0642 |
| 01.90~05.96 | 2400 | 2L-TE | LJ78W | RN1139V | PN1219PN1387 | RN1216V | PN1243 | FN0642 |
| 11.84~12.96 | 2400 | 2LT | LJ70 | RN1823RN1139V | PN1219PN1086 | RN1216V | FN2305PN1243FN2252 | FN0642 |
| 05.93~04.96 | 3000 | 1KZ-TE | KZJ71G | RN1139V | PN1219PN1387 | RN1216V | PN1243 | FN0642 |
| 05.93~04.96 | 3000 | 1KZ-TE | KZJ78W | RN1139V | PN1219PN1387 | RN1216V | PN1243 | FN0642 |
| 11.84~01.90 | 3400 | 3B | BJ70V | RN1139V | PN1086PN1350 | DN1221 | FN2280 | |
| 01.90~01.94 | 3500 | 1PZ | PZJ70 | RN1139V | PN1387PN1219 | DN1222 | FN2280 |
